Ethernet |
| Total Ethernet | 12 |
| 10/100/1000 Mbit/s | 8 |
| SFP 100/1000 Mbit Ports | 4 |
| ethernet_poe_1000mbit | 8 |
| ethernet_poe_standard | 802_3at |
Supported Protocols |
| Managment Protocols | RARP, Syslog, Telnet, TCP, UDP, ARP, ICMP |
| IEEE Standard | IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1S for Multiple Spanning Tree Protocol, IEEE 802.1W for Rapid Spanning Tree Protocol, IEEE 802.1X for Authentication, IEEE 802.3 for 10BaseT, IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3x for Flow Control, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX, IEEE 802.3u for 100BaseT(X) |
System Power Input |
| Input Voltage DC | 46...57 V |
Construction |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 105 mm |
| Depth | 108 mm |
| Height | 154 mm |
Operating Conditions |
| Operating Temperature | -40...75 °C |
Standards and Certifications |
| Certifications | CE, FCC |
| EMI | EN 55022 Class A |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6 |
| Rolling Stock | EN 50121-4 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
