Ethernet | |
| Total Ethernet | 10 |
| 10/100 Mbit/s | 8 |
| Type 10/100 Mbit/s | RJ-45 |
| SFP 100/1000 Mbit Ports | 2 |
Switch Properties | |
| Managed | No |
| Switch Level | Layer 2 |
Supported Protocols | |
| Managment Protocols | TCP, UDP |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3x for Flow Control |
System Power Input | |
| Input Voltage DC | 12...58 V |
Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
Standards and Certifications | |
| Certifications | CE, WEEE, FCC |
| EMI | EN 55022 Class A |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
