Ethernet | |
| Total Ethernet | 20 |
| 10/100 Mbit/s | 16 |
| 10/100/1000 Mbit/s | 4 |
Switch Properties | |
| Managed | No |
| Switch Level | Layer 2 |
Supported Protocols | |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3x for Flow Control |
System Power Input | |
| Input Voltage DC | 12...58 V |
Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight | |
| Width | 138 mm |
| Depth | 97.3 mm |
| Height | 97.3 mm |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| EMI | FCC Part 15, CISPR 22 Class |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
