Ethernet |
| Total Ethernet | 10 |
| 10/100 Mbit/s | 8 |
| Type 10/100 Mbit/s | M12 |
| 10/100/1000 Mbit/s | 2 |
| Type 10/100/1000 Mbit/s | M12 |
| ethernet_poe_100mbit | 8 |
| ethernet_poe_standard | 802_3at |
Supported Protocols |
| Managment Protocols | Syslog, TCP, UDP, SNMP V1, FTP |
| Security Protocols | HTTPS, SSH |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3x for Flow Control |
System Power Input |
| Redundant power input | Yes |
| Input Voltage AC | 24...110 V |
| Power Supply Reserve input Voltage AC | 24...110 V |
Construction |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall |
| Protection Level of Chassis | IP65 |
Operating Conditions |
| Operating Temperature | -40...75 °C |
Standards and Certifications |
| Certifications | CE, FCC |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
