Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Wall |
| Protection Level of Chassis | IP30 |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Atom E3826 |
| Max CPU frequency | 1.46 GHz |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| Mini-PCIe/Mini Card | 2 |
Connectors | |
| Connectors | HDMI, 2xRJ45 Ethernet, 4xUSB, Line Out, DC Input |
System Power Input | |
| Input Voltage DC | 12...12 V |
Software | |
| Operating System Compatibility | Windows 7, Windows Embedded Standard 7, Windows 8, Linux OS, Windows 10 |
Dimensions and weight | |
| Width | 140 mm |
| Height | 170 mm |
| Depth | 50 mm |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class A, FCC |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
