Ethernet |
| Total Ethernet | 24 |
| 10/100/1000 Mbit/s | 24 |
Switch Properties |
| Managed | No |
| Switch Level | Layer 2 |
Supported Protocols |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX |
System Power Input |
| Input Voltage AC | 100...240 V |
Construction |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Built-in, 19" Rackmount |
| Protection Level of Chassis | IP30 |
| Height | 1 U |
Dimensions and weight |
| Width | 280 mm |
| Depth | 180 mm |
| Height | 44 mm |
Operating Conditions |
| Operating Temperature | 0...60 °C |
Standards and Certifications |
| Certifications | CE, FCC |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
