Ethernet | |
| Total Ethernet | 8 |
| 10/100/1000 Mbit/s | 6 |
| SFP 100/1000 Mbit Ports | 2 |
| ethernet_poe_1000mbit | 4 |
| ethernet_poe_standard | 802_3at |
Switch Properties | |
| Switch Level | Layer 2 |
Supported Protocols | |
| Managment Protocols | IGMPv1/v2/v3, VLAN |
| Security Protocols | RADIUS, TACACS+ |
| IEEE Standard | IEEE 802.1ad for Q-in-Q tagging, IEEE 802.1X for Authentication, IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control |
System Power Input | |
| Input Voltage AC | 100...240 V |
Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Built-in, 19" Rackmount, Wall |
| Protection Level of Chassis | IP30 |
Dimensions and weight | |
| Width | 440 mm |
| Depth | 270 mm |
| Height | 44 mm |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
