Ethernet | |
| Total Ethernet | 28 |
| 10/100/1000 Mbit/s | 24 |
| SFP 100/1000 Mbit Ports | 4 |
Switch Properties | |
| Switch Level | Layer 2 |
Supported Protocols | |
| Managment Protocols | SNTP, SNMPv1/v2c/v3, RMON, SNMP V1, NTP |
| Security Protocols | IEEE 802.1X Network Access Control |
| IEEE Standard | IEEE 802.1P for Class of Service, IEEE 802.1Q for VLAN Tagging, IEEE 802.3ad for Port Trunk with LACP |
Connectors | |
| Connectors | DC Input |
System Power Input | |
| Input Voltage AC | 100...240 V |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop, 19" Rackmount |
| Protection Level of Chassis | IP30 |
| Height | 1 U |
Dimensions and weight | |
| Width | 570 mm |
| Depth | 250 mm |
| Height | 44 mm |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
| Vibration | IEC-60068-2-6. |
| Shock | IEC-60068-2-27 |
Standards and Certifications | |
| Certifications | CE, FCC |
| Rolling Stock | EN 50121-4 |
