Ethernet | |
| Total Ethernet | 1 |
| Typical Distance | 2 km |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
System Power Input | |
| Input Voltage DC | 12...55 V |
Operating Conditions | |
| Operating Temperature | -20...75 °C |
Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight | |
| Width | 93 mm |
| Depth | 65 mm |
| Height | 25 mm |
Standards and Certifications | |
| Certifications | CE, FCC |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
