Specification
System Architecture | |
| System Bus | ISA |
Digital Input | |
| Total channels of digital input | 32 |
| Isolation of Digital Input | 3750 V |
| Type | Wet contact |
| Level of Logic "0" | 0~0.8 V |
| Level of Logic "1" | 2~5 V |
Digital Output | |
| Total channels of digital output | 32 |
| Sink/Source | Sink |
| Output voltage | 0~5 V |
| Max. load current | 0.8 mA |
Connectors | |
| Internal Ports | 3x20-pin box header, 20-pin box header |
| Connectors | DB37 Female |
Software | |
| Operating System Compatibility | Linux kernel 2.6, Windows XP, Windows 7, Windows Vista |
| Development Software | VC, VB, Delphi, BCB, LabVIEW |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
