Ethernet | |
| 10/100 Mbit/s | 1 |
| ethernet_poe_100mbit | 4 |
| ethernet_poe_standard | 802_3at, 802_3af |
Supported Protocols | |
| IEEE Standard | IEEE 802.1X for Authentication, IEEE 802.3 for 10BaseT, EE 802.3af for Power-over-Ethernet, IEEE 802.3u for 100BaseT(X) and 100BaseFX |
System Power Input | |
| Redundant power input | Yes |
| Input Voltage DC | 12...48 V |
| Power Supply Reserve input Voltage DC | 12...48 V |
Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall, DIN-Rail mount |
| Protection Level of Chassis | IP40 |
Dimensions and weight | |
| Width | 56 mm |
| Depth | 135 mm |
| Height | 87.8 mm |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
Standards and Certifications | |
| Certifications | CE |
| EMI | FCC Part 15 Subpart B Class A |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
