Display | |
| Display Type | LCD |
| Diagonal | 21.5 " |
| Maximum resolution | 1920x1080 Dots |
| Aspect Ratio | 16:9 |
| Brightness | 250 Cd/m2 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Whiskey Lake |
| Processor Installed | Intel Core i5-8365UE |
| Max CPU frequency | 4.1 GHz |
Chipset | |
| Chipset | Intel Whiskey lake SoC |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in Chipset |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| USB Total | 7 |
| USB 2.0 | 2 |
| USB v3.x | 5 |
Drive interfaces | |
| M.2 | 1 |
| MicroSD | 1 |
Extension Slots | |
| Total | 1 |
| M.2 | 1 |
Connectors | |
| Connectors | HDMI, RJ45 Ethernet, DC Input, MicroSD card slot, USB type A |
System Power Input | |
| Input Voltage DC | 12...12 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Windows IoT Enterprise 10, Windows 10 |
Dimensions and weight | |
| Width | 531 mm |
| Height | 330 mm |
| Depth | 48.5 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
