ITP-800-8PH24

Ціна за запитом
Unmanaged Ethernet PoE Switch with 8x 100 Base-TX PoE Ports, EN50155 Certification, Redundant Dual 24/48VDC Input Power, IP67, -10..+60C Operating Temperature

Specification

Ethernet

Total Ethernet8
10/100 Mbit/s8
Type 10/100 Mbit/s8xM12
PoE 10/100 Mbit/s8

Switch Properties

ManagedNo

Supported Protocols

IEEE StandardIEEE 802.3 for 10BaseT, IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control

System Power Input

Redundant power inputYes
Input Voltage DC20...57 V
Power Supply Reserve input Voltage DC20...57 V

Construction

Construction ChassisMetal Chassis
Mounting ConfigurationWall, DIN-Rail mount
Protection Level of ChassisIP67

Dimensions and weight

Width65.1 mm
Depth66.2 mm
Height191.5 mm

Operating Conditions

Operating Temperature-10...60 °C

Standards and Certifications

CertificationsCE
EMIEN 55022 Class A, FCC Part 15 Subpart B Class A
EMSEN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11, EN 61000-6-2, EN 61000-6-4
Rolling StockEN 50121-4, EN 50155
SafetyUL 60950-1
FreefallIEC 60068-2-32
Vibration And ShockIEC 61373
