System Architecture | |
| Form Factor | Mini-ITX |
CPU | |
| СPU Generation/Family | Braswell |
| Processor Installed | Intel Celeron N3160 |
| Socket | FCBGA1170 |
| Max CPU frequency | 2.24 GHz |
Chipset | |
| Chipset | Intel Braswell SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| ECC | No |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Interfaces | 2xHDMI, LVDS |
Ethernet | |
| Controller Type | Intel i210-AT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 8 |
| USB 2.0 | 4 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Realtek ALC269 |
Drive interfaces | |
| SATA 3 | 1 |
| M.2 | 1 |
Extension Slots | |
| Total | 2 |
| SIM Card slots | 1, Micro-SIM |
| PCI Express x1 | 1 |
| M.2 | 2 |
| M.2 Form Factor | 2230 E, 2242 M |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | 24-pin ATX, USB 3.0 |
| Connectors | DB9, 2xHDMI, PS/2 Keyboard/Mouse, 2xRJ45 Ethernet, 4xUSB, Mic In, Line In, Line Out |
Software | |
| Operating System Compatibility | Windows 8.1 |
Dimensions and weight | |
| Width | 170 mm |
| Length | 170 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
| Humidity | 10-95% |
