Construction | |
| Construction Chassis | Heavy-Duty Steel Chassis |
| Mounting Configuration | 19" Rackmount |
| Height | 2 U |
CPU | |
| Processor Installed | Intel Core i7-3520M |
| Max CPU frequency | 3.6 GHz |
Chipset | |
| Chipset | Intel HM76 |
Memory | |
| Form-factor | DDR3 |
| Socket Type | 1xSODIMM |
| Default on Board Memory | 2 GB |
| Maximum Memory | 16 GB |
Ethernet | |
| Controller Type | Broadcom BCM57780 |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 3 |
| RS-232 | 2 |
| RS-232/422/485 | 1 |
| USB Total | 6 |
| USB 2.0 | 2 |
| USB v3.x | 4 |
Drive interfaces | |
| mSATA | 1 |
Storage Cage | |
| Number Of Cage External | 2 |
| Cage Door | Yes |
| 2.5" Cage External | 2 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | mSATA |
| 1st Storage Capacity | 128 GB |
Extension Slots | |
| PCI | 2 |
LED / Controls | |
| LED | 1xHDD LED, Battеry Status, LAN LED |
| Controls | On/Off, 1xReset |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | 4xCOM |
| Connectors | 3xDB9, DB15 VGA, 2xRJ45, 6xUSB, Mic In, Line In, Line Out, 2xPS/2 Keyboard/Mouse |
System Power Input | |
| Input Voltage AC | 110...240 V |
| Input Voltage DC | 110...240 V |
Dimensions and weight | |
| Width | 482 mm |
| Height | 88 mm |
| Depth | 356 mm |
Operating Conditions | |
| Operating Temperature | -10...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| Power Automation | IEC 61850-3 |
