Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Wall VESA 100 |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Celeron 3765U |
| Max CPU frequency | 1.9 GHz |
Memory | |
| Form-factor | DDR3 |
| Socket Type | 1xSODIMM |
| Default on Board Memory | 4 GB |
| Maximum Memory | 16 GB |
Ethernet | |
| Controller Type | Intel i211, Intel i218 10/100/1000 Mbps |
| Total Ethernet | 4 |
| 10/100/1000 Mbit/s | 4 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| Mini-PCIe/Mini Card | 2 |
| SIM Card slots | 1 |
Connectors | |
| Connectors | DB15 VGA, HDMI, 4xRJ45 Ethernet, 4xUSB, Mic In, Line Out, SIM Card Slot |
System Power Input | |
| Input Voltage DC | 9...36 V |
Software | |
| Operating System Compatibility | Windows Embedded Compact 7, Windows Embedded Standard 8 |
Dimensions and weight | |
| Width | 255 mm |
| Height | 63 mm |
| Depth | 150 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
| Vibration | MIL-STD-810F 514.5C-2 (with SSD) |
| Shock | Half-sine wave shock 5G. 11ms. 3 shocks per axis |
Standards and Certifications | |
| Certifications | CE, FCC |
| MIL-STD-810 | MIL-STD-810F Test Method 514.5C-1 Vibration |
| Vehicle | E-Mark |
