Ethernet |
| Total Ethernet | 10 |
| 10/100/1000 Mbit/s | 10 |
| Type 10/100/1000 Mbit/s | RJ-45 |
| ethernet_poe_1000mbit | 8 |
| ethernet_poe_standard | 802_3at |
Switch Properties |
| MAC Table Size | 4000 |
| Jumbo Frame Size | 9000 kB |
Supported Protocols |
| IEEE Standard | IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3x for Flow Control, IEEE 802.3u for 100BaseT(X) |
System Power Input |
| Input Voltage DC | 9.6...57 V |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 106 mm |
| Depth | 135 mm |
| Height | 55.5 mm |
Operating Conditions |
| Operating Temperature | -10...60 °C |
| Humidity | 5-95% |
Standards and Certifications |
| Certifications | CE |
| EMI | FCC Part 15 Subpart B Class A |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 55032, EN 55035 |
| Vehicle | E-Mark |
| Freefall | IEC 60068-2-32 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
