Construction | |
| Mounting Configuration | Panel, Wall VESA 75 |
Display | |
| Display Type | LCD TFT |
| Diagonal | 7 " |
| Maximum resolution | 800x480 Dots |
CPU | |
| Processor Installed | ARM Cortex A8 |
| Max CPU frequency | 0.72 GHz |
Memory | |
| Default on Board Memory | 0.5 GB |
Drive interfaces | |
| MicroSD | 1 |
| MicroSDHC | 1 |
Software | |
| Operating System Installed | Windows Embedded Compact 7 |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 2 |
Dimensions and weight | |
| Width | 148 mm |
| Depth | 44 mm |
| Height | 213 mm |
System Power Input | |
| Input Voltage DC | 12...48 V |
Operating Conditions | |
| Operating Temperature | -10...60 °C |
