Construction | |
| Mounting Configuration | Panel, Wall VESA 75 |
Display | |
| Display Type | LCD TFT |
| Diagonal | 15 " |
| Maximum resolution | 1024x768 Dots |
CPU | |
| Processor Installed | ARM Cortex A8 |
Memory | |
| Default on Board Memory | 0.5 GB |
Drive interfaces | |
| MicroSDHC | 1 |
| SD Slots | 1 |
Software | |
| Operating System Installed | Windows Embedded Compact 7 |
Ethernet | |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 3 |
| RS-485 | 1 |
| RS-232/422/485 | 2 |
| USB Total | 2 |
Dimensions and weight | |
| Width | 305 mm |
| Depth | 65 mm |
| Height | 381 mm |
System Power Input | |
| Input Voltage DC | 12...48 V |
Operating Conditions | |
| Operating Temperature | -10...60 °C |
