Ethernet |
| Total Ethernet | 1 |
| 10 Gbit/s | 1 |
| 10 Gbit SFP+ Ports | 1 |
Supported Protocols |
| Managment Protocols | SNMPv1/v2c/v3, HTTP, Telnet, LLDP, SNTP, SNMP Trap, Syslog |
| Security Protocols | HTTPS, SSH |
| IEEE Standard | IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3bz for 2.5GBaseX, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX, IEEE 802.3x for Flow Control, IEEE 802ae for 10 Gigabit Ethernet, IEEE 802.1P for Class of Service, IEEE 802.1Q for VLAN Tagging, IEEE 802.1ad for Q-in-Q tagging |
Switch Properties |
| MAC Table Size | 16000 |
| Jumbo Frame Size | 9 kB |
LED / Controls |
| LED | Power LED, LNK/ACT LED |
System Power Input |
| Input Voltage DC | 9...48 V |
Operating Conditions |
| Operating Temperature | -40...75 °C |
| Humidity | 5-95% |
Construction |
| Mounting Configuration | DIN-Rail mount, Wall |
| Protection Level of Chassis | IP40 |
Dimensions and weight |
| Width | 50 mm |
| Depth | 87 mm |
| Height | 135 mm |
Standards and Certifications |
| Certifications | CE, FCC Class A |
| Freefall | IEC 60068-2-32 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
