Ethernet | |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
Interfaces | |
| COM Total | 24 |
| RS-232 | 8 |
| RS-422 | 8 |
| RS-485 | 16 |
Supported Protocols | |
| Industrial Protocols | IEC61850 MMS server, IEC61850 MMS client, DNP3, 60870-5-104 server, 60870-5-104 client, 60870-5-103 slave, 60870-5-103 master, 60870-5-101 slave, 60870-5-101 master, Modbus RTU, Modbus TCP |
| Managment Protocols | DHCP Client, SNMP Trap, FTP, ARP, TFTP, DNS, Syslog, HTTP, NTP Client, SNMP, ICMP |
| Security Protocols | SSH, HTTPS, SSL |
LED / Controls | |
| LED | Power LED, LAN LED, COM-ports LED, ALARM LED indicxator, RUN LED indicxator |
System Power Input | |
| Redundant power input | Yes |
| Input Voltage AC | 85...265 V |
| Power Supply Reserve input Voltage AC | 85...265 V |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
| Humidity | 5-95% |
| MTBF | 30000 h |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | 19" Rackmount |
| Protection Level of Chassis | IP40 |
Dimensions and weight | |
| Width | 483 mm |
| Depth | 200 mm |
| Height | 44 mm |
Connectors | |
| Connectors | Terminal block |
Standards and Certifications | |
| EMI | en55022-cispr22_class_a, fcc_cfr47_part_15 |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-9, IEC 61000-4-10, IEC 61000-4-12, IEC 61000-4-16 |
| Freefall | IEC 60068-2-32 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
