Ethernet |
| Total Ethernet | 6 |
| 10/100 Mbit/s | 4 |
| SFP Fast Ethernet 100 Mbit/s | 2 |
Interfaces |
| COM Total | 8 |
| RS-232/485 | 8 |
Supported Protocols |
| Industrial Protocols | Modbus RTU, Modbus TCP, MQTT, 60870-5-101 master, 60870-5-101 slave, 60870-5-104 server, 60870-5-104 client, 60870-5-103 slave, 60870-5-103 master, OPC UA client, OPC UA server, DNP3, Siemens S7 |
| Reservation protocols | RSTP, STP |
| Managment Protocols | VLAN, DNS, HTTP, SNMP, TFTP, ARP, DHCP Client, NTP Client, SNMP Trap, ICMP |
| Security Protocols | HTTPS, SSH, SSL |
LED / Controls |
| LED | Power LED, LAN LED, COM-ports LED, RUN LED indicxator |
System Power Input |
| Redundant power input | Yes |
| Input Voltage DC | 12...48 V |
| Power Supply Reserve input Voltage DC | 12...48 V |
Operating Conditions |
| Operating Temperature | -40...75 °C |
| Humidity | 5-95% |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | DIN-Rail mount |
| Protection Level of Chassis | IP40 |
Dimensions and weight |
| Width | 45 mm |
| Depth | 208 mm |
| Height | 158 mm |
Connectors |
| Connectors | Terminal block |
Standards and Certifications |
| EMI | fcc_cfr47_part_15, en55032-cispr22_class_a |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-9, IEC 61000-4-10, IEC 61000-4-12, IEC 61000-4-16 |
| Freefall | IEC 60068-2-32 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
