System Architecture | |
| Form Factor | Mini-ITX |
CPU | |
| CPU Support Type | Core i3, Core i5, Core i7 |
| Socket | LGA1151 |
Chipset | |
| Chipset | Intel Q170 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | HDMI, VGA, iDP |
Ethernet | |
| Controller Type | Intel i211, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 5 |
| RS-232/422/485 | 1 |
| USB Total | 10 |
| USB 2.0 | 6 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Realtek ALC662 HD |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| Total | 2 |
| PCI Express x4 | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | 4xSATA 3, 4xUSB 2.0, 10-pin DIO, TPM, 4-pin (12V DC CPU), 24-pin ATX, 4-pin SMBus, iDP, 19-pin USB 3.0, 3x5-pin RS-232 |
| Connectors | DB9, DVI-D, DB15 VGA, PS/2 Keyboard/Mouse, 2xRJ45 Ethernet, 6xUSB, Audio |
Dimensions and weight | |
| Width | 170 mm |
| Length | 170 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
