System Architecture | |
| Form Factor | Mini-ITX |
CPU | |
| Processor Installed | Intel Celeron N2807 |
| Max CPU frequency | 2.16 GHz |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 2xSODIMM |
| Maximum Memory | 8 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | DVI-D, VGA |
Ethernet | |
| Controller Type | Realtek RTL8111E PCIe GbE |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 5 |
| RS-232/485 | 1 |
| USB Total | 8 |
| USB 2.0 | 6 |
| USB v3.x | 2 |
Audio | |
| Audio Controller | Realtek ALC662 HD |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| Total | 2 |
| PCI Express x4 | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | 2xSATA 2, TPM, 4-pin SMBus, 1x4-pin RS-422/485, 3x10-pin RS-232, 4x4-pin USB 2.0, iDP, 6-pin KB/MS, 4-pin ATX |
| Connectors | 2xDB9, DVI-D, DB15 VGA, 2xRJ45 Ethernet, 4xUSB, Audio (in/out/Mic), DC Input |
Dimensions and weight | |
| Width | 170 mm |
| Length | 170 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
