Ethernet | |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
Fiber | |
| Number of Optical Ports | 1xSC |
| Type of Fibre Optic | single-mode |
| Transmission Range | 40 km |
| Length Wave RX/TX | 1310 nm |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-422 | 1 |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
| Humidity | 5-95% |
| MTBF | 1162867 h |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight | |
| Width | 36 mm |
| Depth | 75 mm |
| Height | 100 mm |
Standards and Certifications | |
| Certifications | CE |
| EMI | fcc_cfr47_part_15, en55032-cispr22_class_a |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6 |
| Freefall | IEC 60068-2-32 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
