Ethernet | |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 1 |
| SFP Fast Ethernet 100 Mbit/s | 1 |
Switch Properties | |
| MAC Table Size | 2000 |
| Jumbo Frame Size | 9 kB |
Supported Protocols | |
| IEEE Standard | ieee_802.3i, ieee_802.3u, ieee_802.3ab, ieee_802.3z |
System Power Input | |
| Input Voltage DC | 12...12 V |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Built-in |
| Protection Level of Chassis | IP40 |
Dimensions and weight | |
| Width | 28.8 mm |
| Depth | 98 mm |
| Height | 75.7 mm |
Operating Conditions | |
| Operating Temperature | -10...60 °C |
| Humidity | 5-95% |
Standards and Certifications | |
| EMI | en55022-cispr22_class_a, fcc_cfr47_part_15 |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-6, IEC 61000-4-5, IEC 61000-4-4 |
| Freefall | IEC 60068-2-32 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
