Ethernet | |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
| Type 10/100 Mbit/s | RJ-45 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
Supported Protocols | |
| Security Protocols | HTTPS, SSH2 |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
| Humidity | 5-95% |
Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | DIN-Rail mount |
| Protection Level of Chassis | IP40 |
Dimensions and weight | |
| Width | 30 mm |
| Depth | 68 mm |
| Height | 115 mm |
Standards and Certifications | |
| Certifications | CE/FCC |
| EMI | en_55032, EN 55024, FCC Part 15 Subpart B Class A |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6 |
| Freefall | IEC 60068-2-32 |
| Safety | IEC 60950-1, EN 60950-1 |
| Vibration And Shock | IEC 60068-2-27, IEC 60068-2-6 |
