Construction |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Interfaces |
| COM Total | 1 |
| RS-485 | 1 |
Supported Protocols |
| Industrial Protocols | Modbus RTU slave, DCON slave |
Analog Output |
| Channels of analog input | 1 |
| DAC Bit Rate | 12 Bit |
| Voltage range | 0...10 V |
| Current range | 0...20 mA, 4...20 mA |
Digital Input |
| Total channels of digital input | 3 |
| Type | Dry contact, Wet contact |
| Level of Logic "0" | 0~58 V |
| Level of Logic "1" | 65~240 V |
Digital Output |
| Total channels of digital output | 1 |
| Type | Electromagnitic relay |
| Contact rating of relay (Form A) | 16A@250V AC, 16А@30V DC |
System Power Input |
| Input Voltage DC | 10...30 V |
Dimensions and weight |
| Width | 100 mm |
| Depth | 59 mm |
| Height | 72 mm |
Operating Conditions |
| Operating Temperature | -25...75 °C |
Standards and Certifications |
| EMS | IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5 |
