LD-2104

Ціна за запитом
KYIO-LC Series Remote I/O System Discrete Output Module, KYIO-L, 4-channel digital output/Source/PNP, 5.5-40VDC Single channel maximum 3.3A/4-channel maximum per channel 2A/Channels can be used in parallel/PNP

Specification

Construction

Mounting ConfigurationDIN-Rail mount
Protection Level of ChassisIP20

Digital Output

Total channels of digital output4
Sink/SourceSource
Max. load current2200 mA

System Power Input

Input Voltage DC24...24 V

Dimensions and weight

Width14 mm
Depth75 mm
Height115 mm

Operating Conditions

Operating Temperature-40...85 °C
Humidity5-95%
