Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
CPU | |
| Processor Installed | ARM Cortex A8 |
| Max CPU frequency | 1 GHz |
Memory | |
| Default on Board Memory | 0.5 GB |
Installed drive | |
| Flash Memory Capacity | 512 MB |
| EEPROM Memory Capacity | 64 kB |
| 1st Storage Capacity | 4 GB |
Drive interfaces | |
| MicroSD | 1 |
| MicroSDHC | 1 |
Expansion Module | |
| Quantity of Slots | 1 |
| Supported Module | XV - board |
Software | |
| Operating System Installed | Linux OS |
| Programming Method | C/C++ |
| Development Software | GNU C |
Ethernet | |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 3 |
| RS-232 | 1 |
| RS-485 | 2 |
| USB Total | 1 |
Additional Functions | |
| Watchdog timer type | Hardware, Software |
Connectors | |
| Connectors | Screw Terminal |
Graphic | |
| Interfaces | VGA |
Dimensions and weight | |
| Width | 91 mm |
| Depth | 52 mm |
| Height | 132 mm |
System Power Input | |
| Input Voltage DC | 12...48 V |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
