Ethernet | |
| 10/100/1000 Mbit/s | 2 |
| ethernet_poe_1000mbit | 4 |
| ethernet_poe_standard | 802_3at |
Interfaces | |
| RS-232 | 1 |
Switch Properties | |
| MAC Table Size | 8000 |
| Jumbo Frame Size | 10 kB |
Supported Protocols | |
| IEEE Standard | IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1P for Class of Service, IEEE 802.1Q for VLAN Tagging, IEEE 802.1S for Multiple Spanning Tree Protocol, IEEE 802.1W for Rapid Spanning Tree Protocol, IEEE 802.1X for Authentication, IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3ad for Port Trunk with LACP, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3x for Flow Control, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX |
Connectors | |
| Connectors | DB9, RJ45 |
Construction | |
| Height | 1 U |
Dimensions and weight | |
| Width | 107 mm |
| Depth | 152 mm |
| Height | 72 mm |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
