Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Interfaces | |
| RS-485 | 1 |
Supported Protocols | |
| Industrial Protocols | Modbus RTU slave, DCON slave |
Analog Input | |
| Total channels of analog input | 1 |
| Number of Bits | 16 Bit |
| Sampling rate | 10 Hz |
| Differential channels | 1 |
| Thermal resistance | Pt100, Pt1000, Ni120 |
Digital Input | |
| Total channels of digital input | 1 |
| Type | Dry contact |
| Sink/Source | Source |
Digital Output | |
| Total channels of digital output | 2 |
| Type | Open collector |
| Sink/Source | Source |
| Output voltage | 3.5~50 V |
| Max. load current | 700 mA |
Connectors | |
| Connectors | Screw Terminal |
Additional Functions | |
| Watchdog timer type | Hardware, Software |
System Power Input | |
| Input Voltage DC | 10...30 V |
Dimensions and weight | |
| Width | 72 mm |
| Depth | 35 mm |
| Height | 123 mm |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
