Construction | |
| Construction Chassis | Metal Chassis, Rubber |
| Protection Level of Chassis | IP54 |
| Type | Fanless |
Display | |
| Display Type | LCD IPS |
| Diagonal | 8 " |
| Maximum resolution | 1024x768 Dots |
| Aspect Ratio | 16:9 |
| Brightness | 300 Cd/m2 |
| Contrast Ratio | 400~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Cherry Trail |
| Processor Installed | Intel Atom x5-Z8350 |
| Socket | CPU onboard |
| Max CPU frequency | 1.84 GHz |
Chipset | |
| Chipset | Intel Atom SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | Soldered |
| ECC | No |
| Default on Board Memory | 2 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Integrated in CPU |
Wi-Fi | |
| Wi-Fi Standard | 802.11a/b/g/n/ac |
Interfaces | |
| USB Total | 1 |
| USB 2.0 | 1 |
Drive interfaces | |
| SD Slots | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | eMMC |
| 1st Storage Capacity | 64 GB |
Additional Functions | |
| Camera Frontside | 2 MP |
| Rear Camera | 8 MP |
| NFC | Yes |
Antenna characteristics | |
| Bluetooth | v4.1 |
Connectors | |
| Connectors | 1xMicro USB, MicroSD card slot |
| Docking Station | Yes |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 10 W |
Battery | |
| Battery 1 Technology | Li-ion |
| Battery Capacity | 4000 mA*h |
| RunTime Battery 1 | 3.5 h |
Software | |
| Operating System Compatibility | Android, Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 208.5 mm |
| Height | 150.6 mm |
| Depth | 27 mm |
Operating Conditions | |
| Operating Temperature | -10...45 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
