Construction | |
| Construction Chassis | ABS plastic chassis |
| Protection Level of Front Side (Panel) | IP65 |
| Protection Level of Chassis | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD IPS |
| Diagonal | 10.1 " |
| Maximum resolution | 1280x800 Dots |
| Brightness | 300 Cd/m2 |
| Contrast Ratio | 800~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Celeron N2930 |
| Max CPU frequency | 2.16 GHz |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
Wi-Fi | |
| Wi-Fi Standard | 802.11a/b/g/n |
Interfaces | |
| USB Total | 1 |
| USB v3.x | 1 |
Drive interfaces | |
| mSATA | 1 |
| MicroSD | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | mSATA |
| 1st Storage Capacity | 64 GB |
Extension Slots | |
| SIM Card slots | 1, Yes |
Additional Functions | |
| Camera Frontside | 2 MP |
| Rear Camera | 5 MP |
| GPS | GPS |
| Smart Card Reader | Yes |
| Sensors | Light Sensor, G-sensor, Gyroscope, E-compass |
Antenna characteristics | |
| Cellular interfaces | 3G, 4G |
| Bluetooth | v4.0 |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off, Function Keys, Volume Keys |
Connectors | |
| Connectors | 1xUSB, Mic In, Line Out, DC Input, SIM Card Slot, SD card slot |
| Docking Station | Yes |
System Power Input | |
| Input Voltage DC | 12...19 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 65 W |
| Input Voltage AC | 100...240 V |
Battery | |
| Battery 1 Technology | Li-pol |
| Battery Capacity | 5300 mA*h |
| RunTime Battery 1 | 0 h |
| Battery 1 Hotswap | Yes |
| Additional Battery Type | Li‑pol |
| Additional Battery Capacity | 10600 mA*h |
| RunTime Battery 2 | 0 h |
| Additional Battery Hotswap | Yes |
Software | |
| Operating System Installed | Windows 10 |
Dimensions and weight | |
| Width | 271.8 mm |
| Height | 197.2 mm |
| Depth | 19 mm |
Operating Conditions | |
| Operating Temperature | -10...50 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| MIL-STD-810 | MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock |
| Safety | UL |
