Construction | |
| Construction Chassis | Rubber |
| Protection Level of Chassis | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD IPS |
| Diagonal | 10.1 " |
| Aspect Ratio | 16:10 |
| Brightness | 800 Cd/m2 |
| Contrast Ratio | 800~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Kaby Lake |
| Processor Installed | Intel Core i5-7200U |
Chipset | |
| Chipset | Intel Kaby Lake SoC |
Memory | |
| Socket Type | Soldered |
| ECC | No |
| Default on Board Memory | 8 GB |
| Maximum Memory | 16 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Integrated in CPU, Intel UHD Graphics 620 |
| Interfaces | Micro HDMI |
Wi-Fi | |
| Wi-Fi Standard | Yes |
Interfaces | |
| USB Total | 2 |
Additional Functions | |
| Camera Frontside | 2 MP |
| Rear Camera | 8 MP |
LED / Controls | |
| LED | Battеry Status, Power LED, SSD LED |
| Controls | On/Off, Function Keys, Volume Keys |
Connectors | |
| Connectors | 1xUSB, MicroSD card slot, Micro-SIM card slot, USB type C |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
Battery | |
| Battery 1 Technology | Li-pol |
| Battery Capacity | 5140 mA*h |
| RunTime Battery 1 | 8 h |
| Battery 1 Hotswap | Yes |
Software | |
| Operating System Installed | Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 271.8 mm |
| Height | 197.2 mm |
| Depth | 21 mm |
Standards and Certifications | |
| Certifications | CE, FCC |
| Explosion safety | IECEx, ATEX Zone 2 Group II, UL/cUL Class I Division 2 |
| MIL-STD-810 | MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock |
