Construction | |
| Construction Chassis | Magnesium Alloy |
| Protection Level of Front Side (Panel) | IP65 |
| Protection Level of Chassis | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD |
| Diagonal | 13.3 " |
| Maximum resolution | 1920x1080 Dots |
| Brightness | 350 Cd/m2 |
| Contrast Ratio | 800~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Core i5-7200U |
| Max CPU frequency | 3.1 GHz |
Memory | |
| Form-factor | DDR4 |
| Default on Board Memory | 4 GB |
| Maximum Memory | 16 GB |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Wi-Fi | |
| Wi-Fi Standard | 802.11ac/a/b/g/n |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 5 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Drive interfaces | |
| M.2 | 1 |
| SD Slots | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | M.2 |
| 1st Storage Capacity | 128 GB |
Extension Slots | |
| Total | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Camera Frontside | 2 MP |
| Rear Camera | 5 MP |
| GPS | GPS |
| RFID Reader | Optional |
| Smart Card Reader | Optional |
| Sensors | G-sensor, Gyroscope, Gyro, E-compass |
Antenna characteristics | |
| Cellular interfaces | 3G, 4G |
| Bluetooth | v4.0 |
LED / Controls | |
| LED | Battеry Status, Power LED, SSD LED |
| Controls | On/Off, Control Buttons |
Connectors | |
| Connectors | DB9, HDMI, RJ45 Ethernet, 4xUSB, DC Input, SD card slot |
| Docking Station | Yes |
System Power Input | |
| Input Voltage DC | 12...19 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Input Voltage AC | 100...240 V |
Battery | |
| Battery 1 Technology | Li-pol |
| Battery Capacity | 10280 mA*h |
| RunTime Battery 1 | 0 h |
| Battery 1 Hotswap | Yes |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Windows Embedded Professional 7 (64 bit), Windows 10, Windows Embedded 8.1 Industry |
Dimensions and weight | |
| Width | 338.2 mm |
| Height | 30 mm |
| Depth | 240 mm |
Operating Conditions | |
| Operating Temperature | -10...50 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| MIL-STD-810 | MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock |
| Safety | UL |
