Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Panel, Wall VESA 100 |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 18.5 " |
| Maximum resolution | 1366x768 Dots |
| Aspect Ratio | 16:9 |
| Brightness | 250 Cd/m2 |
| Contrast Ratio | 1000~1 |
| Input Interface | HDMI |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Braswell |
| Processor Installed | Intel Celeron N3160 |
| Socket | FCBGA1170 |
| Max CPU frequency | 1.6 GHz |
Chipset | |
| Chipset | Intel Braswell SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | Soldered |
| ECC | No |
| Default on Board Memory | 4 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | 802.11a/b/g/n |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 3 |
| USB 2.0 | 1 |
| USB v3.x | 2 |
Drive interfaces | |
| mSATA | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | mSATA |
| Drive Interface | SATA |
| 1st Storage Capacity | 32 GB |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off, 1xReset, Volume Keys, Function Keys |
Connectors | |
| Connectors | 2xRJ45 Ethernet, DB9, 3xUSB, Mic In, Line Out, HDMI |
System Power Input | |
| Input Voltage DC | 12...24 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 65 W |
Software | |
| Operating System Compatibility | Windows Embedded 8.1 Industry, Ubuntu |
Dimensions and weight | |
| Width | 500 mm |
| Height | 337 mm |
| Depth | 45 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
| Humidity | 10-95% |
| Vibration | 1 Grms/ 5 ~ 500Hz/ random operation |
| Shock | Operating: 10G/peak (11ms); Non-operating: 10G/peak w/ SSD |
Standards and Certifications | |
| Certifications | CE, FCC |
