Construction | |
| Construction Chassis | ABS plastic chassis |
| Mounting Configuration | Wall VESA 100 |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 18.5 " |
| Maximum resolution | 1366x768 Dots |
| Brightness | 250 Cd/m2 |
| Contrast Ratio | 1000~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | TI Cortex A9 OMAP |
| Socket | CPU onboard |
| Max CPU frequency | 1.5 GHz |
Memory | |
| Form-factor | DDR2 |
| Socket Type | Soldered |
| ECC | No |
| Default on Board Memory | 1 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | 802.11a/b/g/n |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 3 |
| USB 2.0 | 3 |
Drive interfaces | |
| SD Slots | 1 |
LED / Controls | |
| Controls | On/Off, KeyPad |
Connectors | |
| Connectors | DB9, 2xRJ45 Ethernet, 3xUSB, Mic In, Line Out, DC Input, Smart card slot, SD card slot, Audio Mic |
System Power Input | |
| Input Voltage DC | 20...20 V |
Power Supply | |
| Type of Power Supply | Medical, External power adapter AC/DC |
| Output Power | 65 W |
| AC input voltage | 100-220 V |
Software | |
| Operating System Compatibility | Android |
| Operating System Installed | Android |
Dimensions and weight | |
| Width | 500 mm |
| Height | 337 mm |
| Depth | 45 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
| Humidity | 10-95% |
| Vibration | 1 Grms/ 5 ~ 500Hz/ random operation |
| Shock | 10G/peak (11ms) |
Standards and Certifications | |
| Certifications | CE, FCC Class B |
| Medicine | UL 60601-1, EN 60601-1, UL 60601-1-1-2, IEC 60601-1 |
