Construction | |
| Construction Chassis | ABS plastic chassis |
| Protection Level of Front Side (Panel) | IP65 |
| Protection Level of Chassis | IP65 |
| Type | Fanless |
Display | |
| Diagonal | 8 " |
| Maximum resolution | 1280x800 Dots |
| Brightness | 510 Cd/m2 |
| Contrast Ratio | 800~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Pentium N4200 |
| Max CPU frequency | 2.5 GHz |
Memory | |
| Form-factor | DDR4 |
| Default on Board Memory | 4 GB |
Wi-Fi | |
| Wi-Fi Standard | 802.11ac/a/b/g/n |
Interfaces | |
| USB Total | 2 |
| USB v3.x | 2 |
Installed drive | |
| Drive Type | SSD |
| 1st Storage Capacity | 64 GB |
Additional Functions | |
| Camera Frontside | 2 MP |
| Rear Camera | 8 MP |
| GPS | GPS |
| RFID Reader | Optional |
| MSR Reader | Optional |
Antenna characteristics | |
| Cellular interfaces | 3G, 4G |
| Bluetooth | Yes |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off, Function Keys, Volume Keys |
Connectors | |
| Connectors | 2xUSB, Mic In, Line Out, DC Input |
| Docking Station | Yes |
System Power Input | |
| Input Voltage DC | 12...19 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Input Voltage AC | 100...240 V |
Battery | |
| Battery 1 Technology | Li-pol |
| Battery Capacity | 4200 mA*h |
| RunTime Battery 1 | 0 h |
| Additional Battery Type | Li‑pol |
Software | |
| Operating System Installed | Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 225 mm |
| Height | 148 mm |
| Depth | 20.5 mm |
Operating Conditions | |
| Operating Temperature | -10...50 °C |
Standards and Certifications | |
| MIL-STD-810 | MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock |
