System Architecture | |
| Form Factor | Mini-ITX |
CPU | |
| СPU Generation/Family | Bay Trail |
| Processor Installed | Intel Celeron N3160 |
| Max CPU frequency | 2.24 GHz |
Chipset | |
| Chipset | Intel Bay Trail-I SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 2xSODIMM |
| Maximum Memory | 8 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | LVDS, HDMI, VGA |
Ethernet | |
| Controller Type | Realtek RTL8111F 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 4 |
| RS-232/422/485 | 2 |
| USB Total | 6 |
| USB 2.0 | 2 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Realtek ALC662 |
Drive interfaces | |
| mSATA | 1 |
| SD Slots | 1 |
Extension Slots | |
| Total | 2 |
| SIM Card slots | 1 |
| PCI Express x1 | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | SATA 3, 4x10-pin RS-232, 2x4-pin USB 2.0, 4-pin ATX, 20-pin ATX, 40-pin LVDS |
| Connectors | 2xDB9, DB15 VGA, HDMI, PS/2 Mouse, PS/2 Keyboard, 2xRJ45 Ethernet, 4xUSB, Mic In, Line Out, DC Input |
Dimensions and weight | |
| Width | 170 mm |
| Length | 170 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
