CPU | |
| СPU Generation/Family | Comet Lake |
| CPU Support Type | Core i3, Core i5, Core i7, Core i9 |
| Socket | LGA1200 |
Chipset | |
| Chipset | Intel H410 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 5 |
| RS-232/422/485 | 1 |
| USB Total | 7 |
| USB 2.0 | 5 |
| USB v3.x | 2 |
Extension Slots | |
| Total | 4 |
| PCI Express x16 | 1 |
| M.2 | 2 |
| Mini-PCIe/Mini Card | 1 |
Connectors | |
| Internal Ports | COM, 2xSATA 3, USB 2.0, 4-pin (12V DC CPU), 24-pin ATX |
| Connectors | 2xDB9, DB15 VGA, HDMI, Mic In, Line In, Line Out, Display Port |
Software | |
| Operating System Compatibility | Windows 10 |
Dimensions and weight | |
| Width | 170 mm |
| Length | 170 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
