System Architecture | |
| Form Factor | Mini-ITX |
CPU | |
| СPU Generation/Family | Alder Lake |
| Socket | LGA1700 |
Chipset | |
| Chipset | Intel H610 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 64 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | DisplayPort, HDMI, VGA |
Ethernet | |
| Controller Type | Intel i219-V 10/100/1000 Mbps, Intel i225V |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 1 |
| 2,5 Gbit/s | 1 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 3 |
| RS-232/422/485 | 1 |
| USB Total | 7 |
| USB 2.0 | 5 |
| USB v3.x | 2 |
Audio | |
| Audio Controller | Realtek ALC897 |
Drive interfaces | |
| M.2 | 1 |
Extension Slots | |
| Total | 2 |
| PCI Express x16 | 1 |
| M.2 | 1 |
Connectors | |
| Internal Ports | SATA 3, 10-pin DIO, 24-pin ATX, 2x10-pin RS-232, 4-pin USB 2.0, 40-pin LVDS |
| Connectors | 2xDB9, DB15 VGA, HDMI, 2xRJ45 Ethernet, 6xUSB, Audio (in/out/Mic) |
Software | |
| Operating System Compatibility | Windows 10, Windows 11 |
Dimensions and weight | |
| Width | 170 mm |
| Length | 170 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
