Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Built-in, Desktop, Wall, DIN-Rail mount |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Kaby Lake |
| Processor Installed | Intel Core i5-7300U |
| Max CPU frequency | 3.5 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| ECC | No |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Intel HD Graphics 620 |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB v3.x | 3 |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| Total | 3 |
| Mini-PCIe/Mini Card | 3 |
| SIM Card slots | 1 |
Antenna characteristics | |
| Cellular interfaces | 2G, 3G |
Additional Functions | |
| GPS | GPS |
Connectors | |
| Connectors | 2xDB9, HDMI, 2xRJ45 Ethernet, 3xUSB, DC input (terminal block) |
System Power Input | |
| Input Voltage DC | 9...36 V |
Dimensions and weight | |
| Width | 87 mm |
| Height | 134 mm |
| Depth | 130 mm |
Operating Conditions | |
| Operating Temperature | -40...70 °C |
| Shock | IEC 60068-2-27 |
Standards and Certifications | |
| EMI | FCC Part 15 Subpart B Class A |
| EMS | EN 55032 |
| Safety | UL 60950-1, EN 60950-1, EN 62368-1 (LVD), UL 62368-1 |
| Vibration And Shock | IEC 60068-2-27 |
