Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Built-in, Desktop, Wall |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Celeron G3902E |
| Socket | CPU onboard |
| Max CPU frequency | 1.6 GHz |
Chipset | |
| Chipset | Intel QM170 PCH |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xDIMM |
| Default on Board Memory | 4 GB |
| Maximum Memory | 32 GB |
Graphic | |
| Graphic Controller | Intel HD Graphics 510 |
Ethernet | |
| Total Ethernet | 5 |
| 10/100/1000 Mbit/s | 5 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 2 |
| RS-232/422/485 | 2 |
| USB Total | 9 |
| USB 2.0 | 5 |
| USB v3.x | 4 |
Digital Input-Output | |
| Channels of DIO | 8 |
Storage Cage | |
| Number Of Cage External | 2 |
| 2.5" Cage External | 2 |
Connectors | |
| Connectors | 4xDB9, DVI-I, DVI-D, PS/2 Mouse, PS/2 Keyboard, 5xRJ45 Ethernet, 9xUSB, Line In, Line Out, Display Port, 4xNMEA |
System Power Input | |
| Input Voltage AC | 100...240 V |
| Power Consumption | 100 W |
Software | |
| Operating System Compatibility | Linux OS, Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 240 mm |
| Height | 160 mm |
| Depth | 209 mm |
Operating Conditions | |
| Operating Temperature | -25...55 °C |
Standards and Certifications | |
| EMI | FCC Part 15 Subpart B Class A, CISPR 22 Class |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 55024, EN 55032 |
| Marine grade | IEC 60945 4th |
| Safety | UL 60950-1 |
