Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Ethernet |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Supported Protocols |
| Industrial Protocols | Modbus TCP server |
Analog Input |
| Total channels of analog input | 4 |
| Number of Bits | 24 Bit |
| Voltage range | +/-1.25 V, +/-10 V |
| Sampling rate | 128 Hz |
| Differential channels | 4 |
Digital Input |
| Total channels of digital input | 4 |
Digital Output |
| Total channels of digital output | 4 |
| Type | Open collector |
System Power Input |
| Input Voltage DC | 9...30 V |
Dimensions and weight |
| Width | 40 mm |
| Depth | 110.5 mm |
| Height | 126.5 mm |
Operating Conditions |
| Operating Temperature | 0...50 °C |
Standards and Certifications |
| EMI | FCC Part 15 Subpart B Class A, CISPR 32 |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-6-2, EN 61000-6-4 |
