Power Supply | |
| Type of Power Supply | Direct current |
| Output Power | 24 W |
| Output Voltage DC | 24 V |
| Rated current | 1 A |
| AC input voltage | 100-220 V |
| DC Input Voltage | 120-370 V |
Construction | |
| Mounting Configuration | DIN-Rail mount |
Connectors | |
| Connectors | Screw Terminal |
Dimensions and weight | |
| Width | 23 mm |
| Depth | 100 mm |
| Height | 90 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
| Humidity | 20-90% |
| MTBF | 236900 h |
| Temperature (Storage) | -40~+85 |
| Humidity (Storage) | 10~95% |
Standards and Certifications | |
| EMI | EN 61000-3-2, EN 61000-3-3, en55032-cispr32_class_b |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, EN 55024, en_61204-3, en_61000-6-1, EN 55011 |
| Safety | UL 508, en_62368_1 |
| Vibration And Shock | IEC 60068-2-6 |
