Power Supply | |
| Type of Power Supply | Direct current |
| Output Power | 60 W |
| Output Voltage DC | 48 V |
| Rated current | 1.25 A |
| AC input voltage | 100-220 V |
| DC Input Voltage | 120-370 V |
Construction | |
| Mounting Configuration | DIN-Rail mount |
Connectors | |
| Connectors | Screw Terminal |
Dimensions and weight | |
| Width | 40 mm |
| Depth | 100 mm |
| Height | 90 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
| Humidity | 20-90% |
| MTBF | 299200 h |
| Temperature (Storage) | -40~+85 |
| Humidity (Storage) | 10~95% |
Standards and Certifications | |
| EMI | en55032-cispr32_class_b, EN 61000-3-3, EN 61000-3-2 |
| EMS | EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11, EN 61000-6-2, en_61204-3, EN 55024 |
| Safety | UL 508, en_62368_1 |
| Vibration And Shock | IEC 60068-2-6 |
