Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Desktop, Wall |
CPU | |
| Processor Installed | Intel Core i5-6500TE, Intel Core i3-6100TE, Intel Core i7-6700TE, Intel Pentium G4400 |
| CPU Support Type | Core i3, Core i5, Core i7 |
Chipset | |
| Chipset | Intel Q170 |
Memory | |
| Form-factor | DDR4 |
| Default on Board Memory | 32 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 4 |
| RS-232/422/485 | 2 |
| USB Total | 6 |
| USB 2.0 | 2 |
| USB v3.x | 4 |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| PCI Express x16 | 2 |
| PCI Express x4 | 2 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
Connectors | |
| Connectors | DB15 VGA, HDMI, 2xRJ45 Ethernet, 6xUSB, Mic In, Line Out, Display Port |
System Power Input | |
| Input Voltage DC | 12...36 V |
Dimensions and weight | |
| Width | 253 mm |
| Height | 123 mm |
| Depth | 201 mm |
Operating Conditions | |
| Operating Temperature | -20...50 °C |
