Construction | |
| Mounting Configuration | Wall VESA 75 |
Display | |
| Display Type | LED |
| Diagonal | 23.6 " |
| Maximum resolution | 1920x1080 Dots |
| Aspect Ratio | 16:9 |
| Brightness | 250 Cd/m2 |
| Contrast Ratio | 1000~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Core i3-8100 |
| Max CPU frequency | 3.6 GHz |
Memory | |
| Socket Type | 1xSODIMM |
| Maximum Memory | 32 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | 802.11ac/a/b/g/n |
Interfaces | |
| COM Total | 2 |
| RS-232 | 2 |
| USB Total | 4 |
| USB v3.x | 4 |
Drive interfaces | |
| mSATA | 1 |
Connectors | |
| Connectors | 2xDB9, HDMI, 2xRJ45, 4xUSB, Audio |
System Power Input | |
| Input Voltage DC | 12...24 V |
| Power Consumption | 60 W |
Software | |
| Operating System Compatibility | Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 561.9 mm |
| Height | 353.4 mm |
| Depth | 42.9 mm |
Operating Conditions | |
| Operating Temperature | 0...35 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class B, EN 60601 |
| Medicine | EN 60601-1 |
