Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Built-in, Desktop, Wall |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Coffee Lake, Coffee Lake Refresh |
| Socket | LGA1151 |
Chipset | |
| Chipset | Intel Q370 |
Memory | |
| Socket Type | 2xDDR4 SODIMM 260pin |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel i210-AT, Intel i219-LM |
| Total Ethernet | 7 |
| 10/100/1000 Mbit/s | 7 |
Interfaces | |
| COM Total | 6 |
| RS-232/422/485 | 6 |
| USB Total | 8 |
| USB 2.0 | 2 |
Drive interfaces | |
| RAID Levels | 1, 5, 10 |
Storage Cage | |
| Number Of Cage External | 4 |
| 2.5" Cage External | 4 |
Extension Slots | |
| Total | 4 |
| Mini-PCIe/Mini Card | 4 |
Connectors | |
| Connectors | 6xDB9, DVI-D, DB15 VGA, 8xUSB, Mic In, Line In, Display Port, 7xRJ45 Ethernet |
Software | |
| Operating System Compatibility | Linux OS, Windows 10 |
Dimensions and weight | |
| Width | 241.5 mm |
| Height | 92.6 mm |
| Depth | 230 mm |
Standards and Certifications | |
| Certifications | CE, FCC |
